Yanhua ACDP module 28 - 9HP TCU BOOT

Application and selection

Yanhua ACDP module 28 - 9HP TCU BOOT is intended for professional work on the 28 - 9HP TCU BOOT configuration. Car Diag Croatia, an authorised Yanhua distributor, helps verify the required function, matching adapter and software licence before ordering.

Module Function：

Support Jaguar, Land Rover, Chrysler, Dodge, Fiat, Honda, Jeep and other models of the ZF-9HP gearbox BOOT mode clone.

Module Features：

1：The interface board can be inserted blindly to align with the boot test point , no need magnifying glass for calibration or complex probe workbench operation.
2：BOOT test point with pin detection function, data read and write safe and reliable.
3：The special interface board replaces the cable, which is simple, efficient, safe and reliable.

Connection diagram comparison：

APP operation process：

Configuration List:

Application scope

• Data reading and transfer when replacing a compatible controller.

Technical overview

Before ordering

This is an ACDP expansion, not the base programmer. Operation requires a compatible host, the appropriate interface and an activated licence for the selected function. We check your existing equipment and the additions required before ordering.

Compatibility review

Send the vehicle model and year, ECU, TCU or IMMO identifier, required function and the serial number of your existing ACDP unit. Support depends on the specific controller, hardware and activated authorisations; the vehicle brand alone does not establish compatibility.

Request a quotation and compatibility check

Official Yanhua resources

• Modules and technical documentation
• Software and downloads
• Video guides

For qualified professionals working with the vehicle owner’s authorisation. Retain original data and a service record. Work on security and memory systems should follow the official documentation for the exact controller.
